Kinetics and mechanisms of oxidation of d-fructose and d-lactose by permanganate ion in acidic medium

Rafia Azmat, Raheela Naz, Noshab Qamar, Imran Malik

Department of Chemistry University of Karachi.
Department of Chemistry, Jinnah University for Women, 5-C Nazimabad Karachi Pakistan.
International Centre of Chemical and Biological Sciences (ICCBS), University of Karachi.

DOI: 10.4236/ns.2012.47063

Abstract

The oxidations of D-fructose and D-lactose were monitored spectrophotometrically by potassium permanganate in acidic medium at λ_max 545 nm. Reaction demonstrated that the two oxidative species of permanganate were involved in an acidic oxidation of the sugars. It was established that respective acids of sugars as well as arabinonic and formic acid were the oxidation products. Respective acids of sugars were the results of reactive oxygen species of permanganate ions in acidic conditions while arabinonic and formic acids due to the cleavage of C__C bond through MnO^-₄ species. It was first order kinetics with respect to [MnO^-₄ ], [fructose], [lactose] and [H⁺]. Hg was used to accelerate the slow oxidation of lactose. Effect of varying salt electrolyte concentration was insignificant showing that the molecular species was involved in the rate determining step. Formic and arabinonic acids and respective acids were analyzed through spot and spectroscopic studies respectively. Reaction was monitored at different temperatures and thermodynamics activation parameters were determined. A mechanism consistent with kinetic studies, spectral evidences, stoichiometry of the reactions and product analysis has been proposed for the oxidation of fructose and lactose in absence and presence of catalyst respectively.

Keywords

Fructose; Lactose; KMnO₄; Hg; Formic Acid; Arabinonic Acid

1. INTRODUCTION

Carbohydrates are the fuel of life, being the main energy source for living organisms and the central pathway of energy storage and supply for most cells. The study of the carbohydrates and their derivatives has greatly enriched chemistry, particularly with respect to the role of molecular shape and conformation in chemical reactions [1]. Fructose or fruit sugar plays an important role, in mammalian metabolism. It is generally regarded as being 1.73 times as sweet as sucrose [2,3]. Lactose or milk sugar makes up around 2% - 8% of milk (by weight), although the amount varies among species and individuals. Pure lactose and lactose-containing dairy by-products have markedly increased. Purified lactose can also be purchased as high calorie diet additive [4]. These biological and economic importances of the carbohydrates and especially the monosaccharides and disaccarides have been largely responsible for the interest in the study of their bioand physiochemical properties and reactivities [5].

The kinetics of oxidation of sugars by a variety of oxidants have been reported [5-7] in both acidic and alkaline media. Several different mechanisms showing the importance of enediols, cyclic forms of sugars, etc. have been established. Studies involving the oxidation of the sugars by metal ions or their complexes in an alkaline medium are limited [8,9].

The oxidation potential of KMnO₄ as an oxidant is very rarely used for the oxidation of sugars, only few reports were available which discussed the oxidation of sugars and almost all applications of potassium permanganate exploit its oxidizing properties [10], since as a strong oxidant it does not generate toxic by-products. Under acidic condition the KMnO₄ oxidizes alkene and aldehydes to carboxylic acids [11,12].

The objective of the current research was to study the kinetics of oxidation of fructose and lactose by KMnO₄ spectrophotometrically in an acidic medium under various operational parameters to establish the pathway of reaction on the basis of kinetic data and spectroscopic analysis.

1.1. Experimental

All stock solutions for kinetic investigations were prepared in double distilled water. D-fructose, D-lactose, potassium permanganate, sulphuric acid and potassium nitrate used were of Merck, BDH and AR grade. H₂SO₄ and KNO₃ were used to maintain the required acidity and ionic strength respectively. All reactions were studied at constant temperature i.e. 32˚C on a thermostatic water bath. The reaction was initiated by adding sugar solution to the reaction mixture and monitored spectrophotometrically at 545 nm.

Beer Lambert law (A = εcl) was used to analyze the experimental data. According to the Beer-Lambert law, the absorbance (A) of a dilute solution is proportional to its concentration, c and path length l, where ε is molar absorptivity. Change in optical density of was used as reaction monitoring tool at different optimum conditions. Rates of reaction were determined from plots of optical density against time (t) where as a plot of ln A_o − A_∞/A_t − A_∞ was used to determine pseudo-first-order rate constant (k). ln A_o − A_∞/A_t − A_∞ = kt, where A_o, A_t, and A_∞ represents optical density at beginning, at time t and infinity respectively.

1.2. Stoichiometry and Product Analysis

Varying [] and [Sugar] ratios were equilibrated at room temperature for 12 hrs with conditions [] [Sugar]. Estimation of residual [] in different sets showed that 1 mol of sugar consumed 2 (for fructose) and 4 (for lactose) moles of. Following stoichiometric equations could be established.

Fructose         Arabinonic acid  Formic acid

Lactose                     Arabinonic acid  Formic acid

Fructose               Fructuronic acid

Lactose                    Lacturic acid The main products of oxidation like formic and arabinonic acids were identified by TLC and by conventional spot test methods [13] while other oxidation products i.e. fructuronic acid and lacturic acids were identified by Fab mass, ¹H-NMR and ¹³C-NMR spectroscopy.

2. RESULTS

The oxidation reaction for D-fructose and D-lactose with KMnO₄ has been carried out at a constant ionic strength maintained by using KNO₃. The reaction was followed by the change in optical density of KMnO₄ in the reaction mixture at λ_max 545 nm. The rate constants were calculated from the slope of the plot of ln A_o − A_∞/A_t − A_∞ against time. The rate data was obtained in the form of pseudo-first order rate constant. Kinetic results obtained with the variation of from 1 × 10⁻³ - 5 × 10⁻³ mol∙dm⁻³ were presented in the Tables 1 and 2. It was clear from the data that the rate of oxidation of both the sugars was directly proportional to [] throughout its variation. A plot of log k against log [] (Figure 1) gives straight line with a slope near unity (0.94 and 1.2 in fructose and lactose respectively) that also confirms the first order dependence on.

The effect of change in concentration of sugars was monitored by keeping other parameters constant and found first order dependence on the substrate (Tables 1 and 2). These findings were confirmed by the plots of k against [sugar] (Figure 2). The rate of oxidation of lactose was enhanced by adding Hg catalyst. A plot of log k against log [sugar] gives straight lines (Figure 3) with slope equal to 0.84 and 1.2 for fructose and lactose respectively, showing that the order of reaction was approximately unity with respect to both sugars.

Oxidation reactions of sugars were increased in presence of an acid (Tables 1 and 2); showing that the oxidation of sugar takes place through generated reactive oxygen species in solution [14]. A plot of k against [H⁺] was linear with positive intercept on y-axis (Figure 4) for all the substrates which confirms an acid dependence of H⁺ ions concentration.

Effect of change in varying electrolyte concentration was monitored to establish the nature of intermediate species in rate determine step by KNO₃. It was observed that the change in an ionic strength of the medium does not alter the rate constant (Tables 1 and 2). The absence of salt effect indicates that the reaction does not take place

Table 1. Effect of variations of [], [fructose], [H₂SO₄] and ionic strength of the medium on the rate of oxidation at 32˚C.

Table 2. Effect of variations of [], [lactose], [H₂SO₄] and ionic strength of the medium on the rate of oxidation at 32˚C.

Figure 1. A plot of log k vs log [] for the oxidation of fructose and lactose.

Figure 2. A plot of k vs [Sugar] for the oxidation of fructose and lactose by KMnO₄.

Figure 3. A plot of log k vs log [Sugar] for the oxidation of fructose and lactose by KMnO₄.

between ionic species. Hence, at least one of the reacting species in rate determining step was molecular in nature or non-ionic [15]. The slope of the plots between log k against (Figure 5) was zero which confirms the presence of the molecular species in rate determining step.

To evaluate the effect of temperature on rate constant, the oxidation of sugars was carried out at variable temperatures from 30˚C - 50˚C. It was found that the pseudo-first order rate constants increased with an increase in the temperature (Table 3) i.e. the reactions obey Arrhenius plot (Figure 6). Observed values of the rate constants at 30˚C, 35˚C, 40˚C, 45˚C and 50˚C were utilized to calculate E_a, ΔH^#, ΔS^#, ΔG^# (Table 4). The extraordinary negative value of entropy of activation indicates highly solvated state of transition complex showing great degree of freedom of molecules in the transition state as

Figure 4. A plot of k vs [H₂SO₄] for the oxidation of fructose and lactose by KMnO₄.

Figure 5. A plot of vs log k for the oxidation of fructose and lsactose by KMnO₄.

Table 3. Effect of temperature on the rate of oxidation of fructose and lactose.

Table 4. The values of activation parameters at 32˚C.

Figure 6. A plot of ln k vs 1/T for fructose and lactose against KMnO₄ at 0.775 (mol∙dm⁻³)^0.5.

compared to that in the reactive species [16]. The high positive values of free energy of activation also support the formation of solvated transition state [17,18].

3. DISCUSSION

Reactive Species of

There were two main products in each sugar which identified as an arabinonic and formic acid and the respective acids of sugars. These products may be due to the generation of two oxidative species of KMnO₄ in an acidic medium. Respective acids of sugar by the generation of reactive oxygen species in presence of an acid as reported earlier [14] and arabinonic and formic acids [15] due to the breakage of C__C bond by the reactive species of.

On the basis of stoichiometric studies it can be easily concluded that is the active reactive oxidizing specie in an acidic medium which forms permanganic acid when combine with H⁺ ion.

This permanganic acid is a highly oxidative unstable inorganic acid which with catalyst or alone oxidizes the sugar via the formation of unstable intermediate complex which leads to the formation of aldehyde hydrate. This aldehyde hydrate frequently reacts with species and converted into respective carboxylic acid.

4. REACTIVE SPECIES OF Hg(II) CHLORIDE IN AN ACIDIC MEDIUM

In catalyzed oxidation of lactose in an acidic medium, since the solution of catalyst was prepared in the water therefore it was reasonable to assume that the reactive specie of catalyst is [Hg(H₂O)₆]⁺² [19,20].

The above equation was comparable with the work reported earlier [21,22] where kinetic studies have been made for the oxidation of reducing sugars by acidic solution of N-bromophthalimide and NBA in presence of Ir (III) as a homogeneous catalyst. In this case existence of following equilibrium was suggested.

5. SPECTRAL EVIDENCE FOR THE FORMATION OF COMPLEXES DURING COURSE OF THE REACTION

In the kinetic studies of the reducing sugars, it has been observed that the metal ions such as Ru(III) [23] & Pd(II) [24] form complexes with the reducing sugars in an acidic medium. It was also reported [24,25] that the complex thus formed have tendencies to react with the reacting species of NBA & also with Hg(II), whose function in the reaction was as a Br^– ion scavenger and as co-catalyst. In the oxidation of lactose with permanganate ion in acidic medium, order with respect to the sugars concentration was first throughout its 10-fold variation. This shows that OH group of sugar involves in the oxidation before the rate determining step although it will combine with the most reactive complex to form the reaction products along with the regeneration of Hg catalyst.

In order to probe the possible formation of complex and [Hg(H₂O)₆]⁺² spectra for the solution of, H⁺ and for the solution of, H⁺ and [Hg(H₂O)₆]⁺² have been recorded (Figures 7 and 8). From the spectra, it was clear that an addition of [Hg(H₂O)₆]⁺² solution causes an increase in absorbance from 1.79 to 2.00 (l_max 545 nm). This increase in absorbance can be considered as an indication of increased formation of the complex between reactive species of [Hg(H₂O)₆]^{+2 in an acidic medium according to the following equilibrium:}

When lactose solution was added to the solutions of, H⁺ and [Hg(H₂O)₆]^{+2 a decrease in absorbance from 2.00 to 1.99 (}l_max 545 nm) for lactose was observed (Figure 10). This shows that the complex formed subsequently combines with lactose to give a highly solvated activated complex of the types.

according to the following equilibrium

The spectral change due to the addition of fructose in and H⁺ solution clearly indicates that complex formed with fructose due to which absorbance was decreased (Figure 9). This decrease in absorbance with can be considered as an indication of increased formation of the complex between reacting species of and sugar in acidic medium.

6. REACTIONS FOR OXIDATION OF SUGARS INTO ALDONIC ACIDS

Fructose          Arabinonic acid  Formic acid

Lactose                    Arabinonic acid  Formic acid

Reaction Pathway for the Oxidation of Fructose

where R = C₄H₉O₅

Scheme 1. Formation of formic and arabinonic acid as a result of oxidation of fructose.

Reaction Pathway for Catalytic Oxidation of Lactose

Scheme 2. Formation of formic and arabinonic acid as a result of oxidation of lactose.

7. REACTIONS FOR OXIDATION OF SUGARS INTO OTHER CARBOXYLIC ACIDS

Reaction Pathway for Oxidation of Fructose in Absence of Catalyst

where R = C₅H₉O₅

Scheme 3. Formation of fructuronic acid as a result of oxidation of fructose.

Reaction Pathway for Oxidation of Lactose in Presence of Catalyst

where R = C₁₁H₁₇O₁₁

Scheme 4. Formation of lacturic acid as a result of oxidation of lactose.

8. PROPOSED MECHANISM OF KINETICS OF OXIDATION AGAINST KMnO₄

Thus based on above experimental facts, the proposed reaction mechanism involves the formation of [O] [14] by action of H₂SO₄ on KMnO₄.

The permanganate ion reacts with fructose to form complex [C₆H₁₁O₆-]. This complex finally gives an aldonic acid in presence of nucleophile.

The probable rate law might be proposed.

Figure 7. Absorption spectra of and H⁺ solutions.

Figure 8. Absorption spectra of, H⁺ and [Hg(H₂O)₆]⁺² solutions.

Figure 9. Absorption spectra of, H⁺ and fructose solutions.

where RCHO represents the concentration of fructose or lactose and is of Oxidant. The following mechanism was proposed to explain the pathway of oxidation of lactose in presence of Hg catalyst:

Figure 10. Absorption spectra of, H⁺, [Hg(H₂O)₆]⁺² and lactose solutions.

slow where k₁ and k₂ represent the rate constant in the forward and reverse direction and k₃ is the rate constant of the formation of product. Rate of formation of complex will be given as:

(1)

At steady state,

(2)

From eqs.1 and 2 concentration of complex comes out to be:

(3)

At steady state rate of disappearance of may be:

(4)

(5)

Now the total [] may be considered as:

(6)

Now put the value of Complex

(7)

From eq.7 the value of [] comes out:

(8)

The final rate law from 5 to 8:

(9)

(10)

In present experimental conditions,

Hence above equation reduces to,

(11)

where,.

The above equation indicates first order kinetics with respect to sugar and permanganate ion concentration.

9. COMPARATIVE STUDIES

The results of the present study of the oxidation of fructose and lactose by potassium permanganate in acidic medium were compared with the results supported for the oxidation of some aldoses by chromium peroxydichromate in very dilute sulphuric acid [26] and the reactivities of some aldoses and aldoseamines towards potassium bromate in hydrochloric acid medium [1]. In present work , it was found that the is the reactive species of potassium permanganate in acidic as well as in alkaline medium, as far as the kinetic order with respect to is concerned, it was first order throughout the variation of []. The reported first order kinetics with respect to [sugar] was similar with the present study [1,27]. The effect of H⁺ ion concentration have the same effect as in the oxidation of some aldoses by peroxydichromate in dilute sulphuric acid [26] and reactivities of some aldoses and aldoseamines towards potassium bromate in hydrochloric acid medium.

10. CONCLUSIONS

The following conclusions were drawn from the observed kinetic data and the spectral informations collected for the oxidation of fructose and lactose by potassium permanganate in acidic medium while Hg was used in the oxidation of lactose.

1) and [Hg (H₂O)₆]⁺² have been assumed as the reactive species of potassium permanganate and Hg(II) in acidic medium.

2) The complex,

and the complex,

has been proposed as the most unstable activated complex in the oxidation of fructose and lactose respectively.

3) The formation of highly solvated activated complex (schemes 1-4) is supported by observed negative value of entropy of activation.

4) First order kinetics has been observed with respect to oxidant and sugar.

5) Linear dependence of rate is observed when acidity of medium increased.

6) The rate of oxidation of fructose and lactose is unaffected by the change in ionic strength of the medium.

7) Formic acid and arabinonic acid are identified as main oxidation products along with the other acids such as fructuronic and lacturic acid.

Conflicts of Interest

The authors declare no conflicts of interest.
