Aesthetic gingival management: Preservation of the anatomical structures and the gingival aesthetics by immediate implant-insertion after loss of anterior teeth and premolars—Results of a 5-year prospective study with 348 inserted one-phase implants

Angelo Troedhan, Izabela Schlichting, Andreas Kurrek

Center for Facial Esthetics Vienna, Vienna, Austria.
Implantology Clinic Ratingen, Ratingen, Germany.

DOI: 10.4236/ojst.2013.32027

Abstract

Implant insertion is an alternative to classical treatment with bridges after tooth extraction or traumatic tooth loss in the anterior and premolar region of the upper and lower jaw. Nevertheless both types of prosthetic treatment inhere major gingival aesthetic pitfalls by physiological vertical and horizontal resorption. Aim of the study was to investigate if the immediate insertion of root analogue single-stage implants and prosthetic treatment could prevent gingival recessions and bone resorption thus keeping the natural gingival aesthetics untouched. Between 2003 and 2006, 348 root analogue Q1-Implants (TRINON Karlsruhe GmbH/Germany) were inserted in 342 patients’s premolar and molar regions immediately after tooth extraction or traumatic tooth loss and treated with provisional resin crowns. The observation period with recurring 6-month clinical and radiographic check-ups was a minimum of 5 years. Of 348 inserted implants 4 (1.15%) were lost resulting in an overall success rate of 98.85%. In the first 12 weeks after surgery a mean recession of the buccal gingival margin of 0.2 mm (SD 0.34) could be detected, after final prosthetic treatment an overall mean recession of 0.2 mm (SD 0.13) within the survey period. Immediate implant insertion of root analogue single stage implants and immediate prosthetic treatment with provisional resin crowns after minimal invasive tooth extraction seems to be appropriate to prevent bone resorptions of the buccal alveolar crest and the recessions of the gingiva and papillae and

thus suggests to be the preferable treatment to keep the natural gingival and papillary aesthetics untouched preventing further traumatic surgical gingival reconstructions.

Keywords

Oral Implantology; Single Phase Implants; Immediate Implant Insertion; Gingival Aesthetics

Conflicts of Interest

The authors declare no conflicts of interest.

References

[1]	Cawood, J.I. and Howell, R.A. (1991) Reconstructive preprosthetic surgery: I. Anatomical considerations. International Journal of Oral and Maxillofacial Surgery, 20, 75-82. doi:10.1016/S0901-5027(05)80711-8
[2]	Bartee, B.K. (2001) Extraction site reconstruction for alveolar ridge preservation. Part 1: Rationale and materials selection. Journal of Oral Implantology, 27, 187-193. doi:10.1563/1548-1336(2001)027<0187:ESRFAR>2.3.CO;2
[3]	Roccuzzo, M., Bunino, M., Needleman, I. and Sanz, M. (2002) Periodontal plastic surgery for treatment of localized gingival recessions: A systematic review. Journal of Clinical Periodontology, 3, 178-194.
[4]	Oates, T.W., Robinson, M. and Gunsolley, J.C. (2003) Surgical therapies for the treatment of gingival recession. A systematic review. Annals of Periodontology, 8, 303- 320. doi:10.1902/annals.2003.8.1.303
[5]	Becker, W., Gabitov, I., Stepanov, M., Kois, J., Smidt, A. and Becker, B.E. (2010) Minimally invasive treatment for papillae deficiencies in the esthetic zone: A pilot study. Clinical Implant Dentistry and Related Research, 12, 1-8. doi:10.1111/j.1708-8208.2009.00247.x
[6]	Stein, R.S. (1966) Pontic-residual ridge relationship: A research report. Journal of Prosthetic Dentistry, 16, 251- 285. doi:10.1016/0022-3913(66)90080-1
[7]	Schropp, L., Wenzel, A., Kostopoulos, L. and Karring, T. (2003) Bone healing and soft tissue contour changes following single-tooth extraction: A clinical and radiographic 12-month prospective study. The International Journal of Periodontics and Restorative Dentistry, 23, 313- 323.
[8]	Denissen, H.W., Kalk, W., Veldhuis, H.A. and van Waas, M.A. (1993) Anatomic considerations for preventive implantation. The International Journal of Oral & Maxillofacial Implants, 8, 191-196.
[9]	Schropp, L., Kostopoulos, L. and Wenzel, A. (2003) Bone healing following immediate versus delayed placement of titanium implants into extraction sockets—A prospective clinical study. The International Journal of Oral & Maxillofacial Implants, 18, 189-199.
[10]	Kalk, W., Denissen, H.W. and Käyser, A.F. (1993) Preventive goals in oral implantology. International Journal of Dentistry, 43, 483-491.
[11]	Wheeler, S.L., Vogel, R.E. and Casellini, R. (2000) Tissue preservation and maintenance of optimum esthetics: A clinical report. The International Journal of Oral & Maxillofacial Implants, 15, 265-271.
[12]	Fugazzotto, P.A. (2002) Simplified technique for immediate implant insertion into extraction sockets: Report of technique and preliminary results. Implant Dentistry, 11, 79-82. doi:10.1097/00008505-200201000-00018
[13]	Quirynen, M., Van Assche, N., Botticelli, D. and Berglundh, T. (2007) How does the timing of implant placement to extraction affect outcome? The International Journal of Oral & Maxillofacial Implants, 22, 203-223.
[14]	Kan, J.Y.K. and Rungcharassaeng, K. (2003) Interimplant papilla preservation in the esthetic zone: A report of six consecutive cases. The International Journal of Periodontics and Restorative Dentistry, 23, 249-259.
[15]	Kois, J.C. (2001) Predictable single tooth periimplant esthetics: Five diagnostic keys. Compendium of Continuing Education in Dentistry, 22, 199-208.
[16]	Kan, J.Y.K., Rungcharassaeng, K. and Lozada, L. (2003) Immediate placement and provisionalization of maxillary anterior single implants: 1-year prospective study. The International Journal of Oral & Maxillofacial Implants, 18, 31-39.
[17]	Kan, J.Y.K., Rungcharassaeng, K., Umezu, T. and Kois, J.C. (2003) Dimensions of peri-implant mucosa: An evaluation of maxillary anterior single implants in humans. Journal of Periodontology, 74, 563-568. doi:10.1902/jop.2003.74.4.557
[18]	Spear, F.M. (1999) Maintenance of the interdental papilla following anterior tooth-removal. Practical Periodontics and Aesthetic Dentistry, 11, 21-28.
[19]	Garber, D.A., Salama, M.A. and Salama, H. (2001) Immediate total tooth replacement. Compendium of Continuing Education in Dentistry, 22, 210-218.
