Influence of Ferric and Ferrous Iron on Chemical and Bacterial Leaching of Copper Flotation Concentrates

DOI: 10.4236/ijnm.2012.13006   PDF   HTML     8,755 Downloads   13,408 Views   Citations


The effects of ferrous and ferric iron as well as redox potential on copper and iron extraction from the copper flotation concentrate of Sarcheshmeh, Kerman, Iran, were evaluated using shake flask leaching examinations. Experiments were carried out in the presence and absence of a mixed culture of moderately thermophile microorganisms at 50?C. Chemical leaching experiments were performed in the absence and presence of 0.15 M iron (ferric added medium, ferrous added medium and a mixture medium regulated at 420 mV, Pt. vs. Ag/AgCl). In addition, bioleaching experiments were carried out in the presence and absence of 0.1 M iron (ferric and ferrous added mediua) at pulp density 10% (w/v), inoculated bacteria 20% (v/v), initial pH 1.6, nutrient medium Norris and yeast extract addition 0.02% (w/w). Abiotic leaching tests showed that the addition of iron at low solution redox potentials significantly increased the rate and extent of copper dissolution but when ferric iron was added, despite a higher initial rate of copper dissolution, leaching process stopped. Addition of both ferrous and ferric iron to the bioleaching medium levelled off the copper extraction and had an inhibitory effect which decreased the final redox potential. The monitoring of ferrous iron, ferric iron and copper extraction in leach solutions gave helpful results to understand the behaviour of iron cations during chemical and bacterial leaching processes.

Share and Cite:

Ahmadi, A. (2012) Influence of Ferric and Ferrous Iron on Chemical and Bacterial Leaching of Copper Flotation Concentrates. International Journal of Nonferrous Metallurgy, 1, 42-48. doi: 10.4236/ijnm.2012.13006.

Conflicts of Interest

The authors declare no conflicts of interest.


[1] G. Rossi, “Biohydrometallurgy,” McGraw Hill, Hamburg, 1990.
[2] N. Hiroyoshi, M. Hirota, T. Hirajima and M. Tsunekawa, “A Case of Ferrous Sulfate Addition Enhancing Chalcopyrite Leaching,” Hydrometallurgy, Vol. 47, No. 1, 1997, pp. 37-45. doi:10.1016/S0304-386X(97)00032-7
[3] N. Hiroyoshi, H. Miki, T. Hirajima and M. Tsunekawa, “Enhancement of Chalcopyrite Leaching by Ferrous Ions in Acidic Ferric Sulfate Solutions,” Hydrometallurgy, Vol. 60, No. 3, 2001, pp. 185-197. doi:10.1016/S0304-386X(00)00155-9
[4] N. Hiroyoshi, H. Kitagawa and M. Tsunekawa, “Effect of Solution Composition on the Optimum Redox Potential for Chalcopyrite Leaching in Sulfuric Acid Solutions,” Hydrometallurgy, Vol. 91, No. 1-4, 2008, pp. 144-149. doi:10.1016/j.hydromet.2007.12.005
[5] A. Pinches, P. J. Myburgh and C. Merwe, “Process for the Rapid Leaching of Chalcopyrite in the Absence of Catalysis,” US patent No. 6277341 B1, 2001.
[6] K.A. Third, R. Cord-Ruwisch and H. R. Watling, “Control of the Redox Potential by Oxygen Limitation Improves Bacterial Leaching of Chalcopyrite,” Biotechnology and Bioengineering, Vol. 78, No. 4, 2002, pp. 433- 441. doi:10.1002/bit.10184
[7] A. Sandstr?m, A. Shchukarev and J. Paul, “XPS Characterisation of Chalcopyrite Chemically and Bio-Leached at High and Low Redox Potential,” Minerals Engineering, Vol. 18, No. 5, 2005, pp. 505-515. doi:10.1016/j.mineng.2004.08.004
[8] E. M. Cordoba, J. A. Munoz, M. L. Blázquez, F. González and A. Ballester, “Leaching of Chalcopyrite with Ferric Ion. Part IV: The Role of Redox Potential in the Presence of Mesophilic and Thermophilic Bacteria,” Hydrometallurgy, Vol. 93, No. 3-4, 2008. pp. 106-115. doi:10.1016/j.hydromet.2007.11.005
[9] M. Gericke, Y. Govender and A. Pinches, “Tank Bioleaching of Low-Grade Chalcopyrite Concentrates Using Redox Control,” Hydrometallurgy, Vol. 104, No. 3-4, 2010, pp. 414-419. doi:10.1016/j.hydromet.2010.02.024
[10] A. Ahmadi, M. Schaffie, Z. Manafi and M. Ranjbar, “Electrochemical Bioleaching of High Grade Chalcopyrite Flotation Concentrate in a Stirred Tank Reactor,” Hydrometallurgy, Vol. 104, No. 1, 2010, pp. 99-105. doi:10.1016/j.hydromet.2010.05.001
[11] A. Ahmadi, M. Schaffie, J. Petersen, A. Schippers and M. Ranjbar, “Conventional and Electrochemical Bioleaching of Chalcopyrite Concentrates by Moderately Thermophile Bacteria at High Pulp Density,” Hydrometallurgy, Vol. 106, No. 1-2, 2011, pp. 84-92. doi:10.1016/j.hydromet.2010.12.007
[12] T. Das, S. Ayyappan and G. R. Chaudhury, “Factors Affecting Bioleaching Kinetics of Sulfide Ores Using Acidophilic MicroOrganisms,” BioMetals, Vol. 12, No. 1, 1999, pp. 1-10. doi:10.1023/A:1009228210654
[13] J. L. Barron and D. R. Lueking, “Growth and Maintenance of Thiobacillus ferrooxidans Cells,” Applied and Environmental Microbiology, Vol. 56, 1990, pp. 2801- 2806.
[14] D. Howard and F. K. Crundwell, “A Kinetic Study of the Leaching of Chalcopyrite with Sulfolobus Metallicus,” Biohydrometallurgy and the Environment toward the Mining of the 21st Century, 1999, pp. 209-217.
[15] P. R. Norris and D. W. Barr, “Growth and Iron Oxidation by Acidophilic Moderate Thermophiles,” FEMS Microbiology Letters, Vol. 28, No. 3, 1985, pp. 221-224. doi:10.1111/j.1574-6968.1985.tb00795.x
[16] L. Zhang, G.-Z. Qiu, Y.-H. Hu, X.-J. Sun, J.-H. Li and G.-H. Gu, “Bioleaching of Pyrite by A. ferrooxidans and L. ferriphilum,” Transactions of Nonferrous Metals Society of China, Vol. 18, No. 6, 2008, pp. 1415-1420. doi:10.1016/S1003-6326(09)60018-2
[17] K. Nyavor, N. O. Egiebor and P. M. Fedorak, “The Effect of Ferric Ion on the Rate of Ferrous Oxidation by Thiobacillus ferrooxidans,” Applied Microbiology and Biotechnology, Vol. 45, No. 5, 1996, pp. 688-691. doi:10.1007/s002530050749
[18] Y. Kawabe, C. Inoue, K. Suto and T. Chida, “Inhibitory Effect of High Concentrations of Ferric Ions on the Activity of Acidithiobacillus ferrooxidans,” Journal of Bioscience and Bioengineering, Vol. 96, No. 4, 2003, pp. 375-379.
[19] C. Klauber, “A Critical Review of the Surface Chemistry of Acidic Ferric Sulfate Dissolution of Chalcopyrite with Regards to Hindered Dissolution,” International Journal of Mineral Processing, Vol. 86, No. 1-4, 2008, pp. 1-17. doi:10.1016/j.minpro.2007.09.003
